FM Transmitter 150Watts
Harga | Rp 1,00 |
Ketersediaan Barang | Tak Terbatas |
Lebih Lengkap Mengenai FM Transmitter 150Watts
Alta calidad a un precio muy atractivo.
Ideal para su uso como transmisores en aplicaciones independientes.
Potencia ajustable de 10 a 100%
PRIMARY APPLICATION: high
quality at a very attractive price. Ideal for use as transmitters in
stand-alone applications. Adjustable power output from 10 to 100%.
AUDIO PERFORMANCE: low distortion and intermodulation values and a high noise/signal ratio.
HARDWARE FEATURES: compact (525mm depth only) and indeformable thanks to the stainless steel chassis, in 3 rack units only.
USER-FRIENDLY FEATURES: four pushbuttons for user/device interaction and software that offers a simple, intuitive interface.
EASE OF MAINTENANCE: advanced module engineering ensures extreme of access and simple maintenance.
OPERATING EFFICIENCY: incorporate a PFC (Power Factor Corrector) power
supply, that provides the utmost efficiency for enhanced energy saving
and environmental protection, which added to LD-MOSFET technology ensure
high efficiency, better than 70% across the bandwidth.
RELIABILITY/CONTINUITY: APC (Automatic Power Control) and Foldback
protection ensure reliable operation under any operating conditions.
INTERFACE CONTROL: total control thanks to microprocessor easily programmed from menu with all key parameters displayed on LCD.
INPUT/OUTPUT INTERFACE: built-in high-performance stereo coder, L&R
analogue audio inputs, Mono inputs, MPX composite signal and auxiliary
inputs for SCA / RDS signals.
RDS APPLICATION: built-in RDS encoder with UECP standard functions (option).
REMOTE CONTROL: built-in telemetry system via GSM modem, battery and battery charger or via WEB or via SNMP (option).
REGULATORY COMPLIANCE: state-of-the-art technology in full compliance with EC, FCC and CCIR standards.
Features:
- Potencia de salida: ajustable de 0 a 1600 W
- Salida de RF: 50 Ohmios (tipo N)
- Rango de frecuencia: FCC-CCIR-OIRT-JPN-CHN
- Tipo de modulaciĆ³n: Direct Carrier Frequency
- Consumo: 2285 W
- Sistema de enfriamiento: Forzado con ventilador interno
