6 Input HD broadcast quality switcher

6 Input HD broadcast quality switcher
Klik pada gambar untuk memperbesar
Harga
Rp 1,00
Ketersediaan Barang
Tak Terbatas

Lebih Lengkap Mengenai 6 Input HD broadcast quality switcher

The SE-2200 6 input multi-definition switcher is perfect for live production, religious worship, meetings or conference purposes.

It is a technically smart and cost effective portable broadcast-quality switcher.

SE-2200 is a solution that comes with a great features such as 6x6 SDI genlocked Matrix, Dual PIP and built-in title overlay system that works with entry level Datavideo CG systems, or other graphics programmes.

SE-2200 consists of 6 HD-SDI video inputs or with a combination of 4 HD-SDI and 2 HDMI inputs; all of the inputs are reassignable, thus it is able to adapt to your needs. One of the HDMI inputs can be used to accept video from a PC/Laptop computer to work with built-in title overlay system such as Datavideo's CG solutions, including CG-200.

Features:

-Channels: 6
-Video Inputs:
4 x HD-SDI
2 x HD-SDI or HDMI (selectable)
-Video Outputs:
6 x HD-SDI (assignable)
2 x HDMI (Multi-View PVW)
-Supported Input Resolutions:
1080i 50/59.94/60
720p 50/59.94/60
-Audio Inputs 4 x XLR (2 stereo pair)
-Audio Outputs 2 x XLR (1 stereo pair)
-Embedded Audio Supported
-Tally Output 1 x DB25
-Control RS-232, RS-422
-Power 12 VDC, 5 A, 48 W
-Power Adapter 100 to 240 VAC
