The BTU-4D Burk Digital Temperature Unit connects up to four digital temperature sensors to an ARC Solo remote control or to a Plus-X input device in an ARC Plus system. Sensor cables up to 1000 feet long are supported without measurement degradation. The unit also provides a low voltage output sample that tracks linearly with the AC line voltage.


Each temperature output supplies 10mV per degree Fahrenheit or Celsius, based on a jumper setting on the BTU-4D/BTU-4D-I.

The BTU-4D/BTU-4D-I  is supplied with:

One 120 V AC power adapter for BTU-4D or a 220V AC power adapter for BTU-4D-I
One TEMP-OUTDOOR sensor for either Farenheit or Celcius temperature measurement
One 6‐terminal Phoenix-style plug for connection to monitoring equipment

Features:

-Connect up to 4 digital temperature sensors
-Sensor cable length to 1000' without degradation
-Selectable Fahrenheit or Celcius
-One TEMP-OUTDOOR sensor included with each BTU-4D or BTU-4DI
