PCI Sound Cards

PCI Sound Cards
Klik pada gambar untuk memperbesar
Rp 1,00
Ketersediaan Barang
Tak Terbatas

Lebih Lengkap Mengenai PCI Sound Cards

The ASI6544 and ASI6540 are professional PCI sound cards designed for use in radio broadcast automation.Providing 12 play streams that are mixed to 4 balanced stereo outputs and 8 record streams fed from 4 balanced stereo inputs, the ASI6544  and ASI6540 both feature AudioScience’s unique “anything to anywhere” mixing and routing.

The ASI6544 provides both balanced analog and AES/EBU inputs and outputs. The ASI6540 has analog I/O only. The maximum analog input and output level is +24dBu.

A choice of uncompressed PCM, MPEG layer 2 and MP3 is available for both recording and playback. All compression is handled by an on-board floating point DSP, allowing the host computer to focus on other tasks.

ASI6544 and ASI6540 functionality includes MRX™ multi-rate mixing technology which allows streams of different sample rates and formats to be mixed digitally. TSX™ time scaling allows compression/expansion of any or all playback streams in real time with no change in pitch.  For emerging surround sound applications, SSX2™ mode allows multichannel streams of up to 8 channels to be played, recorded and mixed.


-TSX™ time scaling by up to +/-20%
-SSX2™ mode for multichannel record, playback and mixing
-Balanced stereo analog I/O with levels to +24dBu
-24bit ADC and DAC with 110dB SNR and 0.0015% THD+N
-AES/EBU I/O with sample rate converters on all inputs (ASI6544 only)
-Dedicated AES/ABU and Word clock Sync input (ASI6544 only)
-SoundGuard™ transient voltage suppression on all I/O
-Sort length PCI card format (6.6 inches/168mm)
-Up to 4 cards in one system
-Windows and Linux software drivers available
