Multi Channel Tuner Adapters with HD RADIO/DAB/DAB+
| Harga | Rp 1,00 |
| Ketersediaan Barang | Tak Terbatas |
Lebih Lengkap Mengenai Multi Channel Tuner Adapters with HD RADIO/DAB/DAB+
Audioscience has added HD Radio™ and DAB/DAB+ functionality to its ASI8821 and ASI8921 tuner cards series.
ASI8921-5500
(PCI) and ASI8821-5500 (PCI Express) contain eight tuners that may be
independently programmed to receive analogue FM or any channel from any
DAB/DAB+ multiplex in Band III (168MHz to 240MHz).
Alternatively,
the ASI8921-5000 (PCI) and ASI8821-5000 (PCI Express) contain four
tuners that may be independently programmed to receive analogue FM or
any channel from any DAB/DAB+ multiplex in Band III (168MHz to 240MHz).
In
DAB/DAB+ mode each of the 4 or 8 tuners can decode and stream a channel
from any available digital multiplex including associated Service ID,
Component ID, Ensemble ID, and available PAD data. As an example you may
have 1 channel from 8 different ensembles or 2 sets of 4 from 2
different ensembles… etc.
Recording formats include PCM, MPEG-1
layer2 and MP3. Using MRX, AudioScience’s Multi-Rate miXing technology,
each stream can be recorded at any sample rate between 8 and 48kHz.).
Features:
-Support for HD Radio/DAB/DAB+
-Up to 8 channels of HD Radio/DAB/DAB+ (with appropriate module)
-Up to 8 channels of AM/FM audio capture (with appropriate module)
-PCIe interface (ASI8821) or PCI interface(ASI8921)
-Up to 8 channels of FM RBDS/RDS data capture
-AM/FM tuners can be fed from individual external antennas
-Audio monitoring of all tuners simultaneously
-MRX technology allows each stream to have an independent sample rate of between 8 and 48kHz
-PCM and MPEG-1 Layer 2 and MP3 recording formats
-Half-length PCI card
-Up to 8 cards in one system
-Windows and Linux software drivers available
