PCI Express Sound Card
| Harga | Rp 1,00 |
| Ketersediaan Barang | Tak Terbatas |
Lebih Lengkap Mengenai PCI Express Sound Card
The ASI6622 and ASI6620 are professional
PCI-Express sound cards designed for use in radio broadcast
automation.Providing 6 play streams that are mixed to 2 balanced stereo
outputs and 4 record stream fed from 2 balanced stereo input, the
ASI6622 and ASI6620 feature AudioScience’s unique “anything to anywhere”
mixing and routing.
The ASI6622 provides a balanced analog
inputs and outputs. The ASI6620 has analog I/O only. The maximum analog
input and output level is +24dBu.
A choice of uncompressed PCM,
MPEG layer 2 and MP3 is available for both recording and playback. All
compression is handled by an on-board floating point DSP, allowing the
host computer to focus on other tasks.
ASI6622 and ASI6620
functionality includes MRX multi-rate mixing technology which allows
streams of different sample-rates and formats to be mixed digitally. TSX
time scaling allows compression/expansion of any or all playback
streams in real time with no change in pitch
Features:
-TSX time scaling by up to +/-20%
-Balanced stereo analog I/O with levels to +24dBu
-24bit ADC and DAC with 110dB SNR and 0.0015% THD+N
-AES/EBU I/O with sample rate converters on all inputs (ASI6622 only)
-Dedicated AES/EBU and Word clock Sync input
-Short length PCI card format (6.6 inches/168mm)
-Up to 4 cards in one system
-Windows and Linux software drivers available
